EXC
These bolted-compression clamps are designed for making connections between a solid terminal stem and a stranded conductor. the bolted end is intended for bolting to a solid stem, whilst the compression end is designed for crimping onto a stranded conductor. The bolted end is fitted with two independent saddles.
- To connect a solid stem to a stranded conductor by bolting clamp to terminal stem and crimping conductor in compression tube.
- Fasteners M12 GR 8.8 HDG torque to 45Nm.
- Cat No. to be stamped on the substation body casting
- Tube is pre-greased with conductive grease and sealed with plastic cap.
- All terminal palm and conductor surface to be cleaned with stainless steel wire brush and a suitable conductive grease applied before use.
- Material: Cast and Extruded aluminium
- Supplied in clear, sealed, heavy duty,UV stabilized plastic bag.
