Alloy Double Side Tie

Preformed Line Products Alloy Double Side Ties are intended for use in corrosive environments on aluminum based conductors. They are suitable for use on ANSI C29 compliant insulators. Alloy Double Side Ties are designed for use in coastal areas. They have been performance-matched to aluminum conductors and are much more corrosive-resistant than standard aluminized steel ties.

Easily applied by hand or with hot sticks
Performance matched materials
Will not damage the conductor during installation
Conductor application up to 1.24"
Accommodates line angles 0-40° depending on application
Resiliency built in to protect the conductor
Reacts like the conductor under loading
Adheres to NESC Standards
Will hold a minimum of 700 lbs. of unbalanced load (According to rigorous PLP testing)
Suitable for use with either ANSI compliant polymer or porcelain insulators
Made in the USA
