Distribution Tie
The PREFORMEDTM Distribution Tie is intended to secure bare or jacketed conductors in the top groove of vertically mounted insulators.They provide an improved method of securing conductors compared to clamp top insulators or handmade binds.
PREFORMEDTM Distribution Ties with pads are recommended for use with bare conductors. They provide superior abrasion protection for the conductor under all types of motion, including aeolian vibration, galloping and sway.
The PREFORMEDTM Ditribution Tie provides superior abrasion protection for conductors under all types of motion.
PREFORMEDTM Distribution Ties are made of material compatible with the strand to whcih they are applied. For bare conductors, each tie is supplied with a neoprene tie pad.
Lay direction must be the same as that of the outer stranding of the conductor to which it is applied.
Application Procedures
