GUY-LOCK™ Dead-End
The GUY-LOCK DEAD-END is designed to perform the same function as GUY-GRIP® dead-ends, but are for those who prefer a “wrap around” guy at the pole. The GUY-LOCK is recommended for any size pole and neatly secures the tail of the guy strand to the load portion of the down guy. The GUY-LOCK can also be used to secure the down guy at the anchor location.
- Manufactured out of galvanized steel wire
- Installs at either the pole or anchor locations in seconds
- Intended for single use but can be reinstalled twice within 90 days.
- Helically-formed wire dead-end
- One or two piece designs
- Lightweight
- Rated at 100% of the strand's published rated breaking strength
- Recommended for any size pole
- Easily installed on strand sizes ranging from 1/4" (6.35mm) - 1/2" (12.7mm)
Application Procedures
Catalog Pages
GUY-LOCKTM Dead-End - Guying Solutions Catalog
GUY-LOCK
| Catalog Number | Description | Overall Length | Color Code |
| GL-1104 | 1/4" (6.4 mm) | 33" (83.8 cm) | Yellow |
| GL-1106 | 5/16" (7.9 mm) | 35" (88.9 cm) | Black |
| GL-1107 | 3/8" (9.5 mm) | 42" (106.7 cm) | Orange |
| GL-1108 | 7/16" (11.1 mm) | 44" (111.8 cm) | Green |
| GL-1109 | 1/2" (12.7 mm) | 46" (116.8 cm) | Blue |
